ISO 8583 Concepts

ISO 8583 is the international standard for financial transaction card-originated messages. This guide covers the fundamental concepts.

Message Structure

An ISO 8583 message consists of three main parts:

Message Structure

┌─────────┬──────────┬────────────────┐
│   MTI   │  Bitmap  │  Data Fields   │
│ (4 hex) │ (16 hex) │  (variable)    │
└─────────┴──────────┴────────────────┘

MTI (Message Type Indicator)

The MTI is a 4-digit code that identifies the message type:

Position Meaning Values
1 ISO Version 0=1987, 1=1993, 2=2003
2 Message Class 1=Auth, 2=Financial, 4=Reversal
3 Message Function 0=Request, 1=Response, 2=Advice
4 Message Origin 0=Acquirer, 2=Issuer

Common MTIs:

MTI Description
0100 Authorization Request
0110 Authorization Response
0200 Financial Request
0210 Financial Response
0400 Reversal Request
0410 Reversal Response

Bitmap

The bitmap indicates which fields are present in the message. It's a 64-bit (8-byte) or 128-bit (16-byte) field:

  • Primary Bitmap: Fields 1-64
  • Secondary Bitmap: Fields 65-128 (if bit 1 is set)
# Example: Bitmap 7024058020C09000
# Binary: 0111 0000 0010 0100 0000 0101 1000 0000 ...
# Fields present: 2, 3, 4, 7, 11, 14, 22, 24, 25, ...

Data Fields

ISO 8583 defines 128 standard fields. Each field has:

  • Field Number: 1-128
  • Data Type: Numeric, Alpha, Alphanumeric, Binary
  • Length: Fixed or Variable (LLVAR/LLLVAR)

Field Types

Fixed-Length Fields

# Field 3: Processing Code - 6 numeric digits
processing_code = "000000"  # Purchase

# Field 4: Amount - 12 numeric digits
amount = "000000001000"  # $10.00 (in cents)

Variable-Length Fields

Variable fields have a length prefix:

  • LLVAR: 2-digit length prefix (max 99 characters)
  • LLLVAR: 3-digit length prefix (max 999 characters)
# Field 2: PAN (LLVAR)
# "16" prefix + 16-digit PAN
pan_field = "164111111111111111"

# Field 35: Track 2 Data (LLLVAR)
# "037" prefix + 37 characters
track2 = "037411111111111111=2512101123400001"

Key Fields

Field Name Type Description
2 PAN LLVAR Primary Account Number (card number)
3 Processing Code n6 Transaction type (000000=purchase)
4 Amount n12 Transaction amount in minor units
7 Transmission Date/Time n10 MMDDhhmmss
11 STAN n6 System Trace Audit Number
22 POS Entry Mode n3 How card was read
35 Track 2 Data LLVAR Magnetic stripe data
38 Authorization Code an6 Approval code
39 Response Code an2 00=Approved, 05=Declined
41 Terminal ID ans8 Card acceptor terminal ID
42 Merchant ID ans15 Card acceptor ID
55 EMV Data LLLVAR Chip card ICC data (TLV format)

Response Codes (Field 39)

Code Meaning
00 Approved
01 Refer to issuer
05 Do not honor
12 Invalid transaction
13 Invalid amount
14 Invalid card number
51 Insufficient funds
54 Expired card
55 Incorrect PIN

Processing Codes (Field 3)

The 6-digit processing code has three parts:

Digits Meaning
1-2 Transaction Type
3-4 Account Type (From)
5-6 Account Type (To)

Transaction Types:

Code Type
00 Purchase/Goods & Services
01 Cash Withdrawal
09 Purchase with Cash Back
20 Return/Refund
30 Balance Inquiry

EMV Data (Field 55)

Field 55 contains chip card data in TLV (Tag-Length-Value) format:

┌───────┬────────┬───────────────┐
│  Tag  │ Length │     Value     │
│ (1-3) │  (1-3) │  (variable)   │
└───────┴────────┴───────────────┘

Common EMV Tags:

Tag Name
9F26 Application Cryptogram
9F27 Cryptogram Information Data
9F10 Issuer Application Data
9F37 Unpredictable Number
9F36 Application Transaction Counter
82 Application Interchange Profile
9C Transaction Type

Card Networks

Different card networks have specific requirements:

  • VISA: Field 62 (VISA private data), specific response codes
  • Mastercard: Field 48 (additional data), DE127 subfields
  • AMEX: Different field formats, 15-digit PANs
  • Discover: Similar to VISA
  • JCB: Japan-specific requirements
  • UnionPay: China-specific requirements

See the Networks Guide for details.
